WS85 Skid Steer Loader
General specifications of WS85 skid steer loader | |
Engine | Mitsubisht S4S-DT |
Rated power(kw) | 62 |
Rated speed(rpm) | 2500 |
External dimensions: length * width * high | 3688*1817*2023(mm) |
Operating weight(kg) with bucket | 3867 |
Max travelspeed(km/h) | 12 |
Performance | |
Rated operating capacity(kg) | 1050 |
Tipping load(kg) | 2100 |
Max.dump height(mm) | 2543 |
Max.dump distance(mm) | 652 |
Turn radlus,front tyre(mm)(without attachment) | 1346 |
Wheel base(mm) | 1179 |
Bucke capacity(m3) | 0.52 |
Fuel tank capacity(m3) | 88 |
Hydraulic oil tank capacity(m3) | 70 |
Servo Control Configuration Table
Color | Body | Yellow |
Operating Arm | Yellow | |
Back Cover | Yellow | |
Cab | Black | |
Attachment | Black | |
Cab | Air conditioner | |
Heater | Water-cooled engine | |
Fully enclosed drive cabin | ||
Light | Work Light | Yes |
Back-up Buzze | Yes | |
Interior Light | Yes | |
Hydraulic System | Pistion Pump | REXROTH |
High Torque Motor | POCLAIN | |
Pilot Handle | Italy HYDE | |
Gear Pump | PERMCO 33cc | |
Leveling Valve | SAUER DANFOSS | |
Multi-way Valve | Italy HYDE | |
Solenoid Valve | SAUER DANFOSS | |
Engine | Mitsubisht S4S-DT |
Bucket | Auto Balance |
Control | Joystick Control |
Quick-change Hanger | Universal |
Brake | Motor With Brake |
Seat | Safety Belt, |
Solid Tire | 12x16.5 |
Wiper | Yes |
Attachment | Standard Bucket |
Horn | Yes |
Accelerator | Hands-feet |
Rear mirror | Yes |
Auxiliary Hydraulic Control Device | G1 Output Fast Connection |
Loader Body | WS85 |
Oil Tube | 24°International Standard |
Operating Arm Support | Oil Cylinder Fixed Bracket |
Hydraulic oil flow rate | 82.5L/min |
