    XZJ5090TYH(XLY053TB) Pavement Maintenance Vehicle


    1. Overview

    XZJ5090TYH(XLY053TB) pavement maintenance vehicle is applicable for the rapid repair of chuck holes on highway, national and provincial trunk roads, municipal roads and asphalt pavement, and can meet various construction process requirements such as rapid heating of cold finished product mixture, regenerative heating of milling old materials, field frying of asphalt mixture. In addition, the vehicle is characterized by multiple function in one machine, easy operation and high reliability.

    2  Main performance and characteristics

    *Chassis gearbox PTO is adopted to supply power for working devices, reliable performance and convenient maintenance available

    *Adopt gear motor to drive the rotating drum, friction drive, stable operation, low noise, small vibration impact.

    *Heating system for hot-air circulation mixing tank, which is characterized by quick heating and energy conservation and environmental protection, with effective heating volume of 0.5m3.

    *Optimized drum spiral discharging system, which is characterized by quick discharging speed and no residue.

    *It is equipped with hydraulic feeding, asphalt mixture heating, asphalt spraying, discharging, waste storage and other functions. Optional cutting machine, hydraulic crushing picks for rapid cutting and crushing of diseases in base layer and optional walk-behind single drum roller for compaction of road surface.

    *Heat-conducting oil heating asphalt system, which can automatically measure asphalt capacity and achieve precise control;

    *Electrical heating emulsified asphalt spraying system, which adopts automatic telescoping spray tube and has the functions of diesel and pneumatic cleaning;

    *Hydraulic roller lift bracket is placed behind the cab and easy to operate;

    *Hydraulic power (14Mpa) output to connect with attachments swiftly;

    *5kW power output(380V/220V) interface to connect lighting and electric auxiliary tools.

    *High and low voltage instrument box, which can display working parameter in real time and is safe and convenient;

    Item

    Unit

    Parameter

    Product model

    -

    XZJ5090TYH (XLY053TB)

    Working performance parameter

    Drum bunker

    Effective capacity

    m3

    0.5

    Screed heating mode

    /

    Heated air circulation

    Discharging speed

    kg/min

    380

    Feeding hopper capacity

    m3

    0.11

    Single heating time of mixing silo

    min

    15~ 20

    Feeding mode

    /

    Hydraulic automation

    Hot asphalt system

    Tank body capacity

    L

    480

    Screed heating mode

    /

    Diesel burner

    Emulsified asphalt system

    Tank body capacity

    L

    40

    Screed heating mode

    /

    Electrical heating (1kw)

    Diesel cleaning box volume

    L

    15

    Chassis performance parameter

    Type

    /

    Donfeng Duolika EQ1090SJ8BDC

    Engine type

    /

    CY4SK251

    Engine power/speed

    kW/r/min

    115 / 2800

    Driving type

    /

    4×2

    Emission standard

    /

    China Stage V

    Maximum traveling speed

    km/h

    103

    Up-mounted generator parameter

    Type

    /

    FD1F2-4

    Power

    kW/r/min

    22 / 1500

    Overall dimension parameter

    Minimum ground clearance

    mm

    210

    Approach Angle/Departure Angle

    °

    21 / 11.5

    Overall dimension(length× width× height)

    mm

    6600×2340×2950

    Mass parameters of whole machine

    Curb weight

    kg

    8250

    Total mass

    kg

    9400

    Auxiliary tools (optional) :  roller, hydraulic pick, cutting machine, dust collector, blower,  plate hammer and shocking rammer etc.
